Yet Another Parametric Projectbox generator

NextWhat you need

Last updated 11 months ago

This documentation applies to v3.0 (from Februari 2024) and is 'work in progress'

bookshelf

With every electronic circuit I make, there comes a moment when the project is “finished”…. almost!

The last step is always to find a suitable projectbox and even then it is difficult to provide a (often plastic) projectbox with cutouts of the right size and in the right place.

Fortunately I have a 3D printer and in theory I can make a projectbox myself, but it always takes a lot of time. For standard processor boards you can find 3D STL files on the internet, but if you have “designed” a printed circuit board yourself, the only way is a “parameter controlled” solution that you can read in Fusion 360 or in openSCAD. Then you can specify the size of the box via parameters and sometimes a little more, but it never really “fits” well or it is so complex that you have to graduate before you can make something useful with it.

I made a solution that can provide almost any printed circuit board with a nice projectbox: the YAPP generator!

See for more information!

In this book I explain what the principles of this YAPPgenerator are and how you can use it to 3D print beautiful projectboxes!

With the YAPPgenerator as a basis you can make complex project boxes

The name YAPPgenerator is inspired by the Great and Famous (Yet Another Compiler Compiler)

YACC
this post
My gitbook
